мм |
s,мм |
Защитная труба-оболочка |
L´,мм |
Расчетная масса 1м.п. изделия, кг |
||||
|
1 тип |
2 тип |
1 тип |
2 тип |
|||||
|
Dп,мм |
Sп,мм |
Dп,мм |
Sп,мм |
ПЭ |
ПЭ |
|||
|
32 |
3 |
110 |
2.5 |
- |
- |
150 |
3.6 |
- |
|
38 |
3 |
110 |
2.5 |
- |
- |
150 |
4 |
- |
|
45 |
3 |
125 |
2.5 |
- |
- |
150 |
4.8 |
- |
|
57 |
3 |
125 |
2.5 |
140 |
3 |
150 |
5.6 |
6.4 |
|
76 |
3 |
140 |
3 |
160 |
3 |
150 |
7.4 |
8.2 |
|
89 |
4 |
160 |
3 |
180 |
3 |
150 |
10.8 |
11.7 |
|
108 |
4 |
180 |
3 |
200 |
3.5 |
150 |
13 |
14.1 |
|
133 |
4 |
225 |
3.5 |
250 |
3.9 |
150 |
17 |
18.8 |
|
159 |
4.5 |
250 |
3.9 |
280 |
4.4 |
150 |
22.2 |
25.8 |
|
219 |
6 |
315 |
4.9 |
355 |
5.6 |
150 |
38.9 |
42.7 |
|
273 |
7 |
400 |
5.6 |
455 |
5.6 |
210 |
57.2 |
62.1 |
|
325 |
7 |
450 |
5.6 |
500 |
5.6 |
210 |
68.4 |
74.4 |
|
426 |
7 |
560 |
7 |
630 |
7.9 |
210 |
92.2 |
102.3 |
|
530 |
7 |
710 |
8.9 |
- |
- |
210 |
122.3 |
- |
|
630 |
8 |
800 |
10 |
- |
- |
210 |
161.4 |
- |
|
720 |
8 |
900 |
11.2 |
- |
- |
210 |
188.1 |
- |
|
820 |
9 |
1000 |
12.4 |
1100 |
|
210 |
236.8 |
262.1 |
|
920 |
10 |
1100 |
13.8 |
1200 |
|
210 |
292.5 |
318.1 |
|
1020 |
11 |
1200 |
14.9 |
- |
- |
210 |
351 |
- |
|
1220 |
11 |
1425 |
17.3 |
- |
- |
210 |
433.5 |
- |
|
1420 |
12 |
1600 |
19.6 |
- |
- |
210 |
543.3 |
- |
